WEISS TC
Electromechanical indexing table

  • Fixed-station indexing table
  • Permissible torque 150 Nm
  • Mass of inertia 0,06 - 245.840 kgm²
Weiss rotary indexing table TC

Weiss TC fixed station rotary indexing table with smooth, jerk- and impact-free running and extremely long service life. Because the drive can be swung downward the TC rotary indexing table is flexible in using. You can do the conversion work yourself. In order to provide maximum quality and reliability under loaded conditions all bearings are roller bearings that run in an oil bath and the plate cam rollers are mounted on needle bearings

Characteristics TC indexing table

  • Sizes fixed station index table: TC120, TC150, TC220, TC320, TC500, TC700 and TC1000
  • Operating force acting vertically on the locked dial plate up to 80,000 N
  • Radial force acting on the locked dial plate up to 45,000 N
  • Tilting moment acting on the locked dial plate up to 13,000 Nm
  • Permissible inertia up to 245,840 kgm²

Advantages Weiss TC rotary index table

  • Highest reliability
  • Powerful, standing centre part
  • Central bore for cable entries
  • Plate gasket with soiling lip
  • Precise, high-load plate bearing
  • Pin-mounted cam rollers
  • High degree of precision – with even greater precision available on request – always with approval certificate
  • EWR electronic wear compensation through tailor-made control components (EF; TS)
  • Quick response, short lines
  • Renowned manufacturers
  • Profound product knowledge
  • High reliability

We supply slewing ring bearings, oscillating mountings, tensioner devices from stock and we also have spiral bevel gearboxes, servo gears and electromechanical actuators in our delivery program.


In addition we also select and offer the right components and systems for motion control solutions, such as servo gear motors, linear servo actuators and complete XYZ cartesian systems.
