Stöber

Specialist in high precision gearboxes and complete servo systems including inverters and motion controllers.

Select (Click for filters)

>
Brands
>
Stöber

NL +31 297 38 05 62
BE +32 2 588 80 07
stober@atbautomation.eu

Servo motors

EZ

Stober_servo_motors_EZ_serie

High Dynamic servo motors
Stall torque to 100 Nm
Speeds up to 6000 rpm

Servo drives

SC6

Stober SC6 servoregelaar

Stand alone - one and two axis
4 - 19A nominal (peak 210%)
Drive and control based (CiA402)

SI6

Stober SI6 servodrive with PSA power supply

Multi axis drives - central power supply
5 - 50A nominal (peak 210%)
Drive and controller based control (CiA402)

SD6

Stober SD6 high performance servodrive

High performance stand alone drive
1,7 – 85A nominal
Drive and controller based control (CiA402)

Servo geared motors

PE-EZ

Stober_SMS_planetaire-servomotorreductor_PE511_EZ501U_Eco-Line

Planetary gear – precision series
Stall torque to 223 Nm
3:1 – 100:1 / 8-10 arcmin

P-EZ

Stober_SMS_planetaire-servomotorreductor_Classic-Line_P421SGN-EZ402U

Planetary gear – precision series
Stall torque to 2290 Nm
3:1 – 100:1 / 1 – 4 arcmin

PH-EZ

Stober_SMS_planetaire-servomotorreductor_PH-EZ_Power-Line

Planetary gear – precision series
Stall torque to 3948 Nm
4:1 – 100:1 / 1 – 4 arcmin

PHQ-EZ

St?ber_PHQ-EZ-Quattro-Power_Line_open

High Torque planetary– precision series
Stall torque to 14278 Nm
5,5:1 – 100:1 / 1 - 3 arcmin

PKX-EZ

Stober_SMS_planetaire-servomotorreductor_PKX-EZ_Power-Line_haaks

Right-angle planetary servo motor gear
Stall torque to 2119 Nm
3:1 – 210:1 / 3 – 4 arcmin

PK-EZ

Stober_SMS_planetaire-servomotorreductor_PK_EZ_Classic-Line_haaks

Right-angle planetary servo motor gear
Stall torque to 2047 Nm
12:1 – 486:1 / 3,5 – 5 arcmin

PHKX-EZ

Stober_SMS_planetaire-servomotorreductor_PHKX-EZ_Power-Line_haaks

Right-angle planetary servo gear
Stall torque to 2119 Nm
3:1 – 210:1 / 3 – 4 arcmin

PHK-EZ

Stober_SMS_planetaire-servomotorreductor_PHK-EZ_Power-Line_haaks

Right-angle planetary servo gear
Stall torque to 5613 Nm
16:1 – 210:1 / 3 – 4,5 arcmin

PHQK-EZ

Stober_SMS_planetaire-servomotorreductor_PHQK-EZ_Quattro-Power-Line_haaks

High Torque right-angle
Stall torque to 16106 Nm
22:1 – 591:1 / 3,5 - 8 arcmin

KS-EZ

Stober_SMS_planetaire-servomotorreductor_haaks_KS-C_1

Compact planetary right-angle gear
Stall torque to 272 Nm
6 :1 – 100:1 / 4 – 6 arcmin

C-EZ

Stober_SMS_servomotorreductor_C-EZ_coaxiaal

Helical geared servo motor
Stall torque to 4926 Nm
2:1 – 270:1 / 10 – 12 arcmin

F-EZ

Stober_SMS_servomotorreductor_F-EZ_vlak

Offset helical geared servomotor
Stall torque to 827 Nm
4:1 – 274:1 / 5 – 11 arcmin

K-EZ

Stober_SMS_servomotorreductor_K-EZ_kegelwiel

Helical bevel gear servo motor
Stall torque to 10136 Nm
4:1 – 381:1 / 1,5 – 12 arcmin

KL-EZ

Stober_MGS_servomotorreductor_KL_haaks-kegelwiel[1]

Compact helical bevel gear
Stall torque to 43 Nm
8:1 – 32:1 / 16 – 25 arcmin

Lean motors

LM

Stober Lean Motor LM

Compact - High Efficiency IE5
Stall torque to 30 Nm
Power 0,72 - 8,1 kW

CLM

STOBER cLEAN motor IP69K

IP69K - Stainless steel - high efficiency IE5
Torque up to 4,5 Nm at 3000 rpm
Power 0.75 and 1.5 kW

Lean motor gears

PE-LM

Stober PE-LM Leanmotor met planetaire tandwielkast

Compact - High Efficiency IE5
Nominal torque to 177 Nm
Nominal speed 150 - 1000 rpm

P-LM

Stober P-LM Lean motor with planetary gearbox

Compact - High Efficiency IE5
Nominal torque to 1226 Nm
Nominal speed 60 - 1000 rpm

PKX-LM

Stober PKX-LM Leanmotor met haakse planetaire tandwielkast

Compact - High Efficiency IE5
Nominal torque to 2028 Nm
Nominal speed 21 - 1000 rpm

C-LM

Stober C-LM Leanmotor met co-axiale tandwielkast

Compact - High Efficiency IE5
Nominal torque to 3700 Nm
Nominal speed 22 - 1493 rpm

F-LM

Stober F-LM Leanmotor met vlakke opsteek tandwielkast

Compact - High Efficiency IE5
Nominal torque to 912 Nm
Nominal speed 16 - 696 rpm

KL-LM

Stober KS-LM Leanmotor met haakse kegelwieltandwielkast

Compact - High Efficiency IE5
Nominal torque to 36 Nm
Nominal speed 188 - 375 rpm

K-LM

Stober K-LM Leanmotor met haakse kegelwieltandwielkast

Compact - High Efficiency IE5
Nominal torque to 5418 Nm
Nominal speed 10 - 750 rpm

KSS-CLM

cLEAN KSS SS motor reducer

IP69K - Stainless steel - high efficiency IE5
Torques up to 500 Nm
Power 0.75 and 1.5 kW

Servo gears

PE-ME

Stober_ServoFit_planetaire-vertragingskast_PE

Planetary gearbox – economic series
Rated torque to 160 Nm
3:1 – 100:1 / 8 – 10 arcmin

P-ME

Stober ServoFit P

Planetary gearbox – precision series
Rated torque to 2000 Nm
3:1 – 100:1 / 1 – 4 arcmin

PH-ME

Stober_ServoFit_planetary-gearbox_PH

Planetary gearbox – precision series
Rated torque to 5000 Nm
4:1 – 100:1 / 1 – 4 arcmin

PHQ-ME

Stober_planetary-gearbox_PHQ-PHQA

High Torque planetary – precision series
Rated torque to 25000 Nm
5,5:1 – 600:1 / 1- 3 arcmin

PKX-MF

Stober ServoFit haakse-planetaire-vertragingskast PKX

Right-angle planetary gearbox
Rated torque to 2000 Nm
3:1 – 210:1 / 4 – 8,5 arcmin

PK-ME

Stober ServoFit PK

Right-angle planetary gearbox
Rated torque to 2000 Nm
12:1 – 486:1 / 3,5 – 5 arcmin

PHKX-MF

Stober_ServoFit_PHK

Right-angle planetary gearbox
Rated torque to 5000 Nm
4:1 – 300:1 / 3 – 5,5 arcmin

PHK-ME

Stober_ServoFit_PHK

Right-angle planetary gearbox
Rated torque to 5000 Nm
16:1 – 555:1 / 3 – 4,5 arcmin

PHQK-ME

Stober_ServoFit_PHK

High Torque – right-angle gearbox
Rated torque to 13000 Nm
22:1 – 591:1 / 3,5 - 4 arcmin

KS-ME

Stober_ServoFit_Right-angle-servo-gear-box_KS

Compact planetary right-angle gearbox
Rated torque to 400 Nm
6:1 – 200:1 / 4 - 6 arcmin

C-ME

Stober_ServoFit_helical_gear_unit_C

Helical servo gearbox
Rated torque to 7000 Nm
6:1 – 200:1 / 10 - 20 arcmin

F-ME

Stober_ServoFit__Offset-helical-gearbox_F

Offset helical geared servo gearbox
Rated torque to 1100 Nm
4:1 – 552:1 / 5 - 11 arcmin

K-ME

Stober_ServoFit_helical-bevel-gearbox_K

Helical bevel gearbox
Rated torque to 12000 Nm
4:1 – 381:1 / 1,5 - 12 arcmin

KL-MQ

Stober ServoFit helical bevel gear unit KL-V

Compact helical bevel gearbox
Rated torque to 50 Nm
4:1 – 32:1 / 16 - 25 arcmin

ServoStop

Stober_ServoStop_motoradapter-with-brake

Extra brake module in servo gearbox
Motor adapter integrated
Redundancy vertical applications

Rack and pinion drives

ZTRS-ME

Stober_vertragingskast-tandheugel_ZTRS

PH with pionion and bearing support
Module 2 -10 / max 3,9 m/s
Acceleration feed force 15 – 126 kN

ZTR-ME

Stober ZTR-KS en ZTRS-PH

PH and KS gear with pionion
Module 2 -8 / max 4,4 m/s
Acceleration feed force 3,8 - 70 kN

ZR-ME

Stober PH-ZR en KS-ZR

PH and KS gear with pionion
Module 2 -4 / max 6,7 m/s
Acceleration feed force 1,7 - 13 kN

ZV-ME

ST?ER ZV rack and pinion drive

PE-P-PA-PK-PKX-KS-KL-K with pionion
Module 2 -4
Acceleration feed force 5 - 17 kN

Z-EZ

Stober Rack and Pinion drives with servomotor

Servo Gearmotor with Pinion Gear
ZTRS, ZTR, ZR or ZV pinion
Module 2 – 10 / Acceleration force up to 94 kN

ZS

Stober-rack

Racks in combination with Stöber servo gears
Module 2 - 6 / length until 1000 mm
Quality 6

Safety technology

SE6

Safety technology SD6 drive

Safety functions according to EN 61800-5-2
PLe (Cat.4) according to EN ISO 13849-1
Integrated in SD6 servo drive

ST6

ST6

STO according to EN 61800-5-2
PLe (Cat.4) according to EN ISO 13849-1
Integrated in SD6 servo drive

SR6

SR6

STO according to EN 61800-5-2
PLe (Cat.4) according to EN ISO 13849-1
Integrated in SI6 or SC6 servo drive

SY6

SY6

STO and SS1 via FSoE according to EN 61800-5-2
PLe (Cat.4) according to EN ISO 13849-1
Integrated in SI6 or SC6 servo drive

SU6

SU6

STO and SS1 (EN 61800-5-2) via PROFIsafe
PLe (Cat.4) according to EN ISO 13849-1
Integrated in SI6 or SC6 servo drive

SX6

SX6

Fail Safety over EtherCAT / EN 61800-5-2
PLe (Cat. 4) according to EN ISO 13849-1
Integrated in SI6/SC6/SB6 servo controller

Quick response, short lines
Renowned manufacturers
Profound product knowledge
High reliability

Baking tin spray installation with single belt gantry system and Stober servo

We are active in many markets

Various applications in the Benelux, from handling systems to tooling machines or the automotive to food processing industry.

Applications

ATB Automation – specialist in power transmission and motion control

We supply slewing ring bearings, oscillating mountings, tensioner devices from stock and we also have spiral bevel gearboxes, servo gears and electromechanical actuators in our delivery program.

In addition we also select and offer the right components and systems for motion control solutions, such as servo gear motors, linear servo actuators and complete XYZ cartesian systems.
