Wanshsin WTN
Indexing table

  • Indexing table with servo adapter
  • Suitable for 50 to 5500W servo motor
  • Reductions 5 until 100 - 3 arcmin
Wanshsin indexing gear WTN
Wanshsin onderdelen WT draaitafel
WTN side view

The WTN indexing tables have a hollow passage in the middle. The system consists of a single-stage gear unit, a fixed reduction per size and a stainless steel turntable.
Equipped with an adapter with coupling for mounting a servo motor from 50 to 1500 Watt on the input side.
The WTN is equipped with a tapered roller bearing, so that it can be loaded with a high axial load.


8 sizes:

There are 8 sizes available from size 85 to 450 and hollow shaft from 28 to 280 mm.
Single stage ratios from 5:1 to 18:1.
Larger gear ratios are possible by means of a planetary pre-stage.


High accuracy:

  • Backlash 3 arcmin
  • Repeat accuracy +/- 15 arcsec
  • Accurate parallelism and concentricity
  • High permissible moment



  • Quick response, short lines
  • Renowned manufacturers
  • Profound product knowledge
  • High reliability

We supply slewing ring bearings, oscillating mountings, tensioner devices from stock and we also have spiral bevel gearboxes, servo gears and electromechanical actuators in our delivery program.


In addition we also select and offer the right components and systems for motion control solutions, such as servo gear motors, linear servo actuators and complete XYZ cartesian systems.
