Estun ETS-APG-CAN
Three axis servo drive

• Drive for 2 or 3 Estun servo motors
• Max 3 servomotor of 1 kW
• CANopen (speed) and pulse-direction

Estun delivers economical ETS servo systems consisting of one servo controller suitable for driving three Estun servo motors up to 1 kW. The ETS servo controller is equipped with a CANopen communication, and a pulse-direction control signal.
The housing is very compact and robust, and all components are CE and UL certified.
When combined with the Trio motion controller MC403 ATB Automation provides a very economical three-axis servo systems, for example, linear, circular and helical interpolation in XYZ systems.

Typical applications:
•Agriculture and horticulture
• Woodworking Machinery
• XYZ positioning tables

• Downloads
• Applications

• Catalog
• Manual
• Software

•      CAD Downloads

Exhibition demo with Estun and Wanshsin

Demonstration of LEDGO LED panels at an exhibition. Rotations are realized with the Estun three-axis ETS servo drive. The main drive is equipped with a 1 kW servo motor and the two arms of a 400W servomotor. The servomotors are equipped with Wanshsin planetary gearheads with slanting teeth, guaranteeing a low noise level.
